构建机器学习Spark算法库适配代码

构建机器学习算法加速库适配代码Spark-ml-algo-lib过程：

1. 下载Spark 2.3.2源码zip包到“/opt/”目录并解压，得到Spark源码目录“/opt/ spark-2.3.2”。

   获取地址：https://github.com/apache/spark/archive/v2.3.2.zip

   wget https://github.com/apache/spark/archive/v2.3.2.zip unzip v2.3.2.zip

2. 获取Breeze 0.13.1源码zip包到“/opt/”目录并解压，得到Breeze源码目录“/opt/breeze-releases-v0.13.1”。

   获取地址：https://github.com/scalanlp/breeze/archive/releases/v0.13.1.zip

   wget https://github.com/scalanlp/breeze/archive/releases/v0.13.1.zip unzip v0.13.1.zip

3. 在“/opt/”目录下建立一个层级为如下所示的目录的工程Spark-ml-algo-lib。



   cd /opt/
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/breeze/optimize
   mkdir -p Spark-ml-algo-lib/ml-core/src/main/scala/breeze/numerics
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/ml/classification
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/ml/optim/aggregator
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/ml/optim/loss
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/ml/recommendation
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/ml/regression
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/ml/tree/impl
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/clustering
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/fpm
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/linalg/distributed
   mkdir -p Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/tree
   mkdir -p Spark-ml-algo-lib/ml-core/src/main/scala/org/apache/spark/ml/tree/impl
   mkdir -p Spark-ml-algo-lib/ml-core/src/main/scala/org/apache/spark/mllib/clustering
   mkdir -p Spark-ml-algo-lib/ml-core/src/main/scala/org/apache/spark/mllib/fpm
   mkdir -p Spark-ml-algo-lib/ml-core/src/main/scala/org/apache/spark/mllib/tree/impurity

4. 按照表1、表2的对应关系将Spark 2.3.2和Breeze 0.13.1中的对应原文件复制到Spark-ml-algo-lib目录，表格左边两列是目标目录和文件名，右边两列的是需要移动的原文件目录及文件名。由于需要复制的文件很多，操作的代码只给出两个示例。


   有些文件在复制到目标文件夹后需要改名。

   操作命令示例：

   1 2

   cp /opt/spark-2.3.2/mllib/src/main/scala/org/apache/spark/ml/classification/GBTClassifier.scala /opt/Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/ml/classification/GBTClassifier.scala cp /opt/breeze-releases-v0.13.1/math/src/main/scala/breeze/optimize/FirstOrderMinimizer.scala /opt/Bigdata_ML_ALGO_ACC_LIB/ml-accelerator/src/main/scala/breeze/optimize/FirstOrderMinimizerX.scala

   表1 Spark中需要放入Spark-ml-algo-lib工程的文件

   Spark-ml-algo-lib工程目录	Spark-ml-algo-lib工程文件名	Spark原文件所在目录	Spark原文件名
   Spark-ml-algo-lib/ml-accelerator/ src/main/scala/org/apache/spark/ml/classification/	GBTClassifier.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/classification/	GBTClassifier.scala
   	LinearSVC.scala		LinearSVC.scala
   	RandomForestClassifier.scala		RandomForestClassifier.scala
   	DecisionTreeClassifier.scala		DecisionTreeClassifier.scala
   	LogisticRegression.scala		LogisticRegression.scala
   Spark-ml-algo-lib/ml-accelerator/ src/main/scala/org/apache/spark/ml/optim/aggregator/	DifferentiableLossAggregatorX.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/optim/aggregator/	DifferentiableLossAggregator.scala
   	HingeAggregatorX.scala		HingeAggregator.scala
   	HuberAggregatorX.scala		HuberAggregator.scala
   	LeastSquaresAggregatorX.scala		LeastSquaresAggregator.scala
   	LogisticAggregatorX.scala		LogisticAggregator.scala
   Spark-ml-algo-lib/ml-accelerator/ src/main/scala/org/apache/spark/ml/optim/loss/	RDDLossFunctionX.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/optim/loss/	RDDLossFunction.scala
   Spark-ml-algo-lib/ml-accelerator/ src/main/scala/org/apache/spark/ml/regression/	DecisionTreeRegressor.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/optim/loss/	DecisionTreeRegressor.scala
   	GBTRegressor.scala		GBTRegressor.scala
   	LinearRegression.scala		LinearRegression.scala
   	RandomForestRegressor.scala		RandomForestRegressor.scala
   Spark-ml-algo-lib/ml-accelerator/ src/main/scala/org/apache/spark/ml/tree/impl/	GradientBoostedTrees.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/tree/impl/	GradientBoostedTrees.scala
   	NodeIdCache.scala		NodeIdCache.scala
   	RandomForest.scala		RandomForest.scala
   	RandomForest4GBDTX.scala		RandomForest.scala
   	RandomForestRaw.scala		RandomForest.scala
   	DecisionForest.scala		RandomForest.scala
   Spark-ml-algo-lib/ml-accelerator/ src/main/scala/org/apache/spark/ml/tree/	treeParams.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/tree/	treeParams.scala
   Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/clustering/	KMACCm.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/mllib/clustering	KMeans.scala
   	KMeans.scala		KMeans.scala
   Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/linalg/distributed/	RowMatrix.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/mllib/linalg/distributed	RowMatrix.scala
   Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/linalg/	EigenValueDecomposition.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/mllib/linalg	EigenValueDecomposition.scala
   Spark-ml-algo-lib/ml-accelerator/src/main/scala/org/apache/spark/mllib/tree/	DecisionTree.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/mllib/tree	DecisionTree.scala
   Spark-ml-algo-lib/ml-core/ src/main/scala/org/apache/spark/ml/tree/	Node.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/tree/	Node.scala
   	Split.scala		Split.scala
   Spark-ml-algo-lib/ml-core/ src/main/scala/org/apache/spark/ml/tree/impl	BaggedPoint.scala	spark-2.3.2/mllib/src/main/scala/org/ apache/spark/ml/tree/impl/	BaggedPoint.scala
   	DTFeatureStatsAggregator.scala		DTStatsAggregator.scala
   	DTStatsAggregator.scala		DTStatsAggregator.scala
   	GradientBoostedTreesCore.scala		RandomForest.scala
   	TreePointX.scala		TreePoint.scala
   	TreePointY.scala		TreePoint.scala
   Spark-ml-algo-lib/ml-core/src/main/scala/org/apache/spark/mllib/tree/impurity/	Entropy.scala	spark-2.3.2/mllib/src/main/scala/org/apache/spark/mllib/tree/impurity	Entropy.scala
   	Gini.scala		Gini.scala
   	Impurities.scala		Impurities.scala
   	Impurity.scala		Impurity.scala
   	Variance.scala		Variance.scala

   表2 Breeze中需要放入Spark-ml-algo-lib工程的文件

   Spark-ml-algo-lib工程目录	Spark-ml-algo-lib工程文件名	Breeze原文件所在目录	Breeze原文件名
   Spark-ml-algo-lib/ml-accelerator/ src/main/scala/breeze/optimize	FirstOrderMinimizerX.scala	breeze-releases-v0.13.1/math/src/ main/scala/breeze/optimize	FirstOrderMinimizer.scala
   	LBFGSX.scala		LBFGS.scala
   	OWLQNX.scala		OWLQN.scala

   完成4后，Spark-ml-algo-lib工程的目录结构及目录下的文件如下：

   Spark-ml-algo-lib
   ├── ml-accelerator
   │   └── src
   │       └── main
   │           └── scala
   │               ├── breeze
   │               │   └── optimize
   │               │       ├── FirstOrderMinimizerX.scala
   │               │       ├── LBFGSX.scala
   │               │       └── OWLQNX.scala
   │               └── org
   │                   └── apache
   │                       └── spark
   │                           ├── ml
   │                           │   ├── classification
   │                           │   │   ├── DecisionTreeClassifier.scala
   │                           │   │   ├── GBTClassifier.scala
   │                           │   │   ├── LinearSVC.scala
   │                           │   │   ├── LogisticRegression.scala
   │                           │   │   └── RandomForestClassifier.scala
   │                           │   ├── optim
   │                           │   │   ├── aggregator
   │                           │   │   │   ├── DifferentiableLossAggregatorX.scala
   │                           │   │   │   ├── HingeAggregatorX.scala
   │                           │   │   │   ├── HuberAggregatorX.scala
   │                           │   │   │   ├── LeastSquaresAggregatorX.scala
   │                           │   │   │   └── LogisticAggregatorX.scala
   │                           │   │   └── loss
   │                           │   │       └── RDDLossFunctionX.scala
   │                           │   ├── regression
   │                           │   │   ├── DecisionTreeRegressor.scala
   │                           │   │   ├── GBTRegressor.scala
   │                           │   │   ├── LinearRegression.scala
   │                           │   │   └── RandomForestRegressor.scala
   │                           │   └── tree
   │                           │       ├── impl
   │                           │       │   ├── DecisionForest.scala
   │                           │       │   ├── GradientBoostedTrees.scala
   │                           │       │   ├── NodeIdCache.scala
   │                           │       │   ├── RandomForest4GBDTX.scala
   │                           │       │   ├── RandomForestRaw.scala
   │                           │       │   └── RandomForest.scala
   │                           │       └── treeParams.scala
   │                           └── mllib
   │                               ├── clustering
   │                               │   ├── KMACCm.scala
   │                               │   └── KMeans.scala
   │                               ├── linalg
   │                               │   ├── distributed
   │                               │   │   └── RowMatrix.scala
   │                               │   └── EigenValueDecomposition.scala
   │                               └── tree
   │                                   └── DecisionTree.scala
   └── ml-core
       └── src
           └── main
               └── scala
                   └── org
                       └── apache
                           └── spark
                               ├── ml
                               │   └── tree
                               │       ├── impl
                               │       │   ├── BaggedPoint.scala
                               │       │   ├── DTFeatureStatsAggregator.scala
                               │       │   ├── DTStatsAggregator.scala
                               │       │   ├── GradientBoostedTreesCore.scala
                               │       │   ├── TreePointX.scala
                               │       │   └── TreePointY.scala
                               │       ├── Node.scala
                               │       └── Split.scala
                               └── mllib
                                   └── tree
                                       └── impurity
                                           ├── Entropy.scala
                                           ├── Gini.scala
                                           ├── Impurities.scala
                                           ├── Impurity.scala
                                           └── Variance.scala

5. 下载Spark-ml-algo-lib.patch到“/opt/Spark-ml-algo-lib/”目录下，将patch解压后并入Spark-ml-algo-lib，得到完整的机器学习算法加速库适配代码Spark-ml-algo-lib。

   1 2 3

   cd /opt/Spark-ml-algo-lib wget https://github.com/kunpengcompute/Spark-ml-algo-lib/releases/download/v1.1.0/Spark-ml-algo-lib.patch patch -p1 < Spark-ml-algo-lib.patch

   完整的机器学习算法加速库适配代码Spark-ml-algo-lib的目录及目录下的文件如下：

   Spark-ml-algo-lib
   ├── LICENSE
   ├── ml-accelerator
   │   ├── pom.xml
   │   └── src
   │       └── main
   │           └── scala
   │               ├── breeze
   │               │   └── optimize
   │               │       ├── FirstOrderMinimizerX.scala
   │               │       ├── LBFGSX.scala
   │               │       └── OWLQNX.scala
   │               └── org
   │                   └── apache
   │                       └── spark
   │                           ├── ml
   │                           │   ├── classification
   │                           │   │   ├── DecisionTreeClassifier.scala
   │                           │   │   ├── GBTClassifier.scala
   │                           │   │   ├── LinearSVC.scala
   │                           │   │   ├── LogisticRegression.scala
   │                           │   │   └── RandomForestClassifier.scala
   │                           │   ├── optim
   │                           │   │   ├── aggregator
   │                           │   │   │   ├── DifferentiableLossAggregatorX.scala
   │                           │   │   │   ├── HingeAggregatorX.scala
   │                           │   │   │   ├── HuberAggregatorX.scala
   │                           │   │   │   ├── LeastSquaresAggregatorX.scala
   │                           │   │   │   └── LogisticAggregatorX.scala
   │                           │   │   └── loss
   │                           │   │       └── RDDLossFunctionX.scala
   │                           │   ├── regression
   │                           │   │   ├── DecisionTreeRegressor.scala
   │                           │   │   ├── GBTRegressor.scala
   │                           │   │   ├── LinearRegression.scala
   │                           │   │   └── RandomForestRegressor.scala
   │                           │   └── tree
   │                           │       ├── impl
   │                           │       │   ├── DecisionForest.scala
   │                           │       │   ├── GradientBoostedTrees.scala
   │                           │       │   ├── NodeIdCache.scala
   │                           │       │   ├── RandomForest4GBDTX.scala
   │                           │       │   ├── RandomForestRaw.scala
   │                           │       │   └── RandomForest.scala
   │                           │       └── treeParams.scala
   │                           └── mllib
   │                               ├── clustering
   │                               │   ├── KMACCm.scala
   │                               │   └── KMeans.scala
   │                               ├── linalg
   │                               │   ├── distributed
   │                               │   │   └── RowMatrix.scala
   │                               │   └── EigenValueDecomposition.scala
   │                               └── tree
   │                                   └── DecisionTree.scala
   ├── ml-core
   │   ├── pom.xml
   │   └── src
   │       └── main
   │           └── scala
   │               └── org
   │                   └── apache
   │                       └── spark
   │                           ├── ml
   │                           │   └── tree
   │                           │       ├── impl
   │                           │       │   ├── BaggedPoint.scala
   │                           │       │   ├── DTFeatureStatsAggregator.scala
   │                           │       │   ├── DTStatsAggregator.scala
   │                           │       │   ├── GradientBoostedTreesCore.scala
   │                           │       │   ├── TreePointX.scala
   │                           │       │   └── TreePointY.scala
   │                           │       ├── Node.scala
   │                           │       └── Split.scala
   │                           └── mllib
   │                               └── tree
   │                                   └── impurity
   │                                       ├── Entropy.scala
   │                                       ├── Gini.scala
   │                                       ├── Impurities.scala
   │                                       ├── Impurity.scala
   │                                       └── Variance.scala
   ├── ml-kernel-client
   │   ├── pom.xml
   │   └── src
   │       └── main
   │           └── scala
   │               ├── breeze
   │               │   ├── linalg
   │               │   │   ├── blas
   │               │   │   │   ├── Dgemv.scala
   │               │   │   │   └── Gramian.scala
   │               │   │   ├── DenseMatrixUtil.scala
   │               │   │   ├── DenseVectorUtil.scala
   │               │   │   └── lapack
   │               │   │       └── EigenDecomposition.scala
   │               │   └── optimize
   │               │       ├── ACC.scala
   │               │       ├── LBFGSL.scala
   │               │       └── OWLQNL.scala
   │               └── org
   │                   └── apache
   │                       └── spark
   │                           ├── ml
   │                           │   └── tree
   │                           │       └── impl
   │                           │           ├── DTUtils.scala
   │                           │           ├── GradientBoostedTreesUtil.scala
   │                           │           └── RFUtils.scala
   │                           ├── mllib.clustering
   │                           │   └── KmeansUtil.scala
   │                           └── mllib.linalg.distributed
   │                               └── RowMatrixUtil.scala
   ├── pom.xml
   ├── README.md
   └── scalastyle-config.xml
